Self Control Fuse WSFC Series

Description

WSFC Series is a three terminals surface mountable battery protector that can protect against both overcurrent and over-charging. It comprises a fuse element to ensure stable operation under normal electrical current and to cut off the current when overcurrent occurs. It also comprises a resistive heating element that could be used in combination with a voltage detecting means, such as IC and FET. When overvoltage is detected, it will generate heat to blow the fuse to achieve overvoltage protection.

Features

  • Halogen Free
  • Protection for both overcurrent and overcharging
  • Surface Mount
  • Fast response

Electrical Characteristics

Part

Number

Irated

(A)

Cell In

Series

Vmax

(Vdc)

Ibreak

(A)

Vop

(V)

Resistance

Agency Approvals

Rfuse

(mΩ)

UL

WSFC1204

12

1

36

50

4.0-7.0

1.5-3.5

√

WSFC1208

12

2

36

50

4.0-9.0

1.5-3.5

√

WSFC1212

12

3

36

50

7.4-13.8

1.5-3.5

√

WSFC1214

12

4

36

50

10.5-19.6

1.5-3.5

√

WSFC1220

12

5

36

50

14.4-23.5

1.5-3.5

√

WSFC1224

12

6

36

50

15.6-27.0

1.5-3.5

√

WSFC1250

12

13

36

50

36.4-59.8

1.5-3.5

√

WSFC1250-C14

12

14

62

50

42.0-62.0

1.5-3.5

√

WSFC1512

15

3

36

50

7.4-13.8

1.0-3.0

√

WSFC1514

15

4

36

50

10.5-19.6

1.0-3.0

√

WSFC1520

15

5

36

50

14.4-23.5

1.0-3.0

√

WSFC1524

15

6

36

50

17.3-28.20

1.0-3.0

√

WSFC1550

15

16

36

50

36.2-62.0

1.0-3.0

√

WSFC3004

30

1

62

80

4.0-4.7

0.5-2.5

√

WSFC3008

30

2

62

80

7.5-9.0

0.5-2.5

√

WSFC3012

30

3

62

80

9.9-13.5

0.5-2.5

√

WSFC3014

30

4

62

80

13.4-18.4

0.5-2.5

√

WSFC3020

30

5

62

80

17.1-23.5

0.5-2.5

√

WSFC3024

30

6

62

80

19.8-27.0

0.5-2.5

√

WSFC3030

30

6-7

62

80

23.1-31.5

0.5-2.5

√

WSFC3030-C8

30

7-8

62

80

26.5-36.0

0.5-2.5

√

WSFC3040

30

9-10

62

80

34.2-46.9

0.5-2.5

√

WSFC3050

30

13

62

80

45.2-58.5

0.5-2.5

√

WSFC3050-C14

30

12-14

62

80

45.2-62.0

0.5-2.5

√
